JASPER— WOODWORKING MACHINERY —
Models: MDD-1200 / MDD-1500 / MDD-2400
MDD Series CNC Band Sawing Machine
Quick answer: The JASPER MDD Series CNC Band Sawing Machine is for accurate, efficient band sawing of solid wood furniture components. It is suited to chair, table, cabinet, bed, curved wood, and other solid wood parts.
| Available Models | MDD-1200 / MDD-1500 / MDD-2400 |
| Saw Cutting Length | 1200 / 1500 / 2400 mm |
| Saw Cutting Width | 1350 mm |
| Saw Cutting Thickness | 150 mm |
| Saw Blade Length | 5270 mm |
| Main Motor Power | 5.5 kW |
| X Axis Servo | 1.5 / 2.0 kW |
| Machine Weight | 2000 / 2500 / 3000 kg |
Standard Equipment
| Control & Software System | Transmission & Feeding System |
|---|---|
| Advanced CNC control system | Stable transmission system |
| CAD software compatibility | Precision guide and feed components |
| Reliable electrical components | Efficient processing performance |
| Easy operation and maintenance | Safe operating structure |
Technical Parameters
| Item | MDD-1200 | MDD-1500 | MDD-2400 |
|---|---|---|---|
| Saw Cutting Length | 1200 mm | 1500 mm | 2400 mm |
| Saw Cutting Width | 1350 mm | 1350 mm | 1350 mm |
| Saw Cutting Thickness | 150 mm | 150 mm | 150 mm |
| Saw Blade Length | 5270 mm | 5270 mm | 5270 mm |
| Main Motor Power | 5.5 kW | 5.5 kW | 5.5 kW |
| X Axis Servo | 1.5 kW | 1.5 kW | 2.0 kW |
| Y Axis Servo | 0.75 kW | 0.75 kW | 1.0 kW |
| Z Axis Servo | 0.75 kW × 2 | 0.75 kW × 2 | 0.75 kW × 2 |
| Vacuum Mouth Size | 4 pcs × 3 | 4 pcs × 3 | 4 pcs × 3 |
| Machine Size, L × W × H | 970 × 520 × 2330 mm 3150 × 2000 × 1570 mm | 970 × 520 × 2330 mm 3750 × 2000 × 1570 mm | 970 × 520 × 2330 mm 5250 × 2000 × 1570 mm |
| Installation Size, L × W × H | 4500 × 3000 × 2400 mm | 5100 × 3000 × 2400 mm | 6200 × 3000 × 2400 mm |
| Machine Weight | 2000 kg | 2500 kg | 3000 kg |
FAQ
Common Questions
What workpieces is the MDD Series CNC band saw best for?
The MDD Series is best for band sawing solid wood furniture components, including chair, table, cabinet, bed, and curved wood parts.
How do I choose between MDD-1200, MDD-1500, and MDD-2400?
Choose by required saw cutting length: 1200 mm, 1500 mm, or 2400 mm. Each listed model has a 1350 mm cutting width and 150 mm cutting thickness.
What process does the MDD Series perform?
The listed process is CNC band sawing of solid wood components. Review the part drawing, cutting length, width, and thickness before selecting a model.
When is the MDD Series not the right fit?
It is not the right fit when the required cutting length exceeds 2400 mm, the width exceeds 1350 mm, or the thickness exceeds 150 mm.
What is the standard order lead time?
The listed lead time is 30–45 days. The exact timeline is confirmed with the order.
